KPR-SWE-48VAC/DC-2C
2 C/0 PLC Relay
How can I find pricing information?
To access product pricing information, create an order list and contact us.
Min. order quantity : 10
Packing unit : 10 pcs.
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Commercial Information
Product Sales Code
272560
Packing Unit
10 pcs.
Customs Tariff No.
853641900000
Product Description
2 C/0 PLC Relay
Technical Information
general
Connection Type
Screw terminals
Protection Class
IP20
Weight G
64
Packaging Quantity
10
Case Width Mm
14
Mounting Type
Rail Mount
Max Cable Cross Section
2,5
Max Torque
0,4Nm
Insulation Resistance
1000M Ohm (500VDC)
current-measurement-input
Power Consumption
1W DC
Nominal Voltage Un
48VAC/DC
Operating Voltage Range
> %80 x UN
Isolation Voltage
< %30 x UN
Integrated Rcz Filter
----
environmental-conditions
Operating Temperature
-40°C +85°C
Storage Temperature
-40°C +85°C
Relative Humidity Non Condensing
%5 .. %85 (non-condensing)
connection-information
Connection Type
2 C/O (SPDT)
Material
AgSnO2
Coil Voltage
48V
Coil Impedance
1440 x (1 ±10%) Ohm
Coil Consumption
---
Operating Time
15ms max.
Release Time
8ms max.
Max Values Ac
400VAC
Max Values Dc
300VDC
Mechanical Operating Life No
= 10^7 operations
Electrical Operating Life Ul Approved 85c No
3x10^4 operations
Electrical Operating Life Ul Approved 85c Nc
1x10^5 operations
dielectric-strength
Connections Between Relay Coils
5000VAC 1 min.
Connections Between
1000VAC 1 min.
accessories-and-components
Socket Type
KPR-SWE48ACV/VDC-2C (RELAY SOCKET)
Socket Description
PLC RELAY SOCKET (48AC/VDC)
Socket Order Number
272561
Socket Packaging Quantity
10
Relay Type
48ACV/VDC Relay
Relay Description
Relay for 272560
Relay Order Number
095051
Relay Packaging Quantity
10
16 Way Jumper Type
--
16 Way Jumper Description
--
16 Way Jumper Order Number
--
16 Way Jumper Packaging Quantity
--
8 Way Jumper Type
TK-KPR-S (KPR-SWE BRIDGE/8)
8 Way Jumper Description
Plug in bridge - 8
8 Way Jumper Order Number
476900
8 Way Jumper Packaging Quantity
25
Switch 2 Way Jumper Packaging Quantity
--
Switch 2 Way Jumper Order Number
--
Switch 2 Way Jumper Description
--
Switch 2 Way Jumper Type
--
Dekafix Type
DG 10/6T
Dekafix Description
Terminals Lebels for interface relays
Dekafix Order Number
505 390
Dekafix Packaging Quantity
360
Certificates
CE
UKCA
UL
