FKM
Flat Cable Module, 16 channels
How can I find pricing information?
To access product pricing information, create an order list and contact us.
Min. order quantity : 1
Packing unit : 1 pcs.
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Commercial Information
Product Sales Code
116016
Packing Unit
1 pcs.
Customs Tariff No.
853690950000
Weight per piece (inc. packing)
0.132 kg.
Product Description
Flat Cable Module, 16 channels
Technical Information
ELECTRICAL FEATURES
Diode Current
1 A
Diode Reverse Voltage
0.67 V ~
general
Module Length
55 mm
Number Of Poles
16
connection-information
Single Conductor Minimum Cross Section
0.5 mm2
Single Conductor Maximum Cross Section
4 mm²
Multiple Conductor Minimum Cross Section
0.5 mm2
Multiple Conductor Maximum Cross Section
2.5 mm2
Awg Conductor Range
26-14
Connection Type
Screw Type
Cable Stripping Length
7 mm
Tightening Torque
Nm
Certificates
CE
UKCA
ROHS
