B100-0M-V3
3Ø MID Energy Meter
How can I find pricing information?
To access product pricing information, create an order list and contact us.
Min. order quantity : 1
Packing unit : 1 pcs.
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Commercial Information
Product Sales Code
606802
Packing Unit
1 pcs.
Customs Tariff No.
903032009011
Weight per piece (inc. packing)
0.34 kg.
Product Description
3Ø MID Energy Meter
Technical Information
general
Connection Type
3P4W
Real Time Clock
+
Current Connection Type
Direkt Baglantili (100A ya kadar)
energy-measurement
Number Of Tariffs
2
Number Of Reactive Measurement Zones
2
Energy Measurement Type
Import & Export kWh-kVArh
Partial Counter
+
Balance Energy
+
current-measurement-input
Measuring Range
3x 0,25 .. 100A
voltage-measurement-input
Measuring Range L N
100-300V AC
Measuring Range L L
173-520
power-quality-measurements
Thdi
+
Thdv
+
power-supply
Voltage
100-300V AC
Frequency
45-65Hz
Consumption
<3VA AC
mechanical-properties
Weight G
340
Protection Class
IP20
Mounting Type
Rail Mount
environmental-conditions
Operating Temperature
-25°C +50°C
Storage Temperature
-25°C +70°C
Relative Humidity Non Condensing
Max. 80% (no condensation)
digital-output
Frequency
5-30 VDC
Number Of Inputs
2 (1 sabit, 1 ayarlanabilir)
Switched Voltage Range
Transistor
Isolation
3750 Vrms
digital-input
Number Of Inputs
Dry Contact
Input Type
3750 Vrms
Isolation
2
basic-electrical-measurements
Current
+
Voltage
+
Frequency
+
Active Power
+
Reactive Power
+
Apparent Power
+
measurement-class
En 50470
Class B
measurement
Demand
+
led-impulse
Kwh
+
Kvarh
+
Certificates
CE
UKCA
UL
